High Bending Strength Tungsten Carbide Flat Plate for
Cold Pressing YG20C
Description:
Tungsten Carbide plate is one of the tungsten steel materials which uses metallurgical methods through milling, ball milling, pressing, sintering. Different uses in WC and Co of tungsten carbide plates is different. Tungsten carbide plate has high hardness, good wear resistance, high elastic modulus, high strength, good chemical stability(stable for acid, base, high temperature oxidation), lower impact toughness, low expansion coefficient, thermal conductivity, conductive characteristics of similar to iron and its alloy. It is also an excellent material for making high-temperature parts, wear-resistant parts, shielded parts and corrosion-resistant parts. When select suitable tungsten steel sheet, be careful according to actual usage.
Hard alloy brand performance and recommendation of wear resistant materials:
| Grade | Hardness
HRA | TRS
N/mm² | Density
g/cm³ | Recommended Applications |
| YG6X | 92 | 1800 | 14.9 | It can be used for the steel wire, non-ferrous metal wire or rod die under the condition of less stress. |
| YG6 | 90.5 | 2000 | 14.9 | It can be used for steel wire, non-ferrous metal and alloy bars under 20mm diameter with greater stress condition, and can also be used to pull tubing with a diameter of less than 10mm. |
| YG8 | 90 | 2200 | 14.7 | It can be use in steel, non-ferrous metal and alloy bars and pipes, and also for manufacturing machinery parts, tools and vulnerable parts. |
| YG8.2 | 89 | 2000 | 14.6 |
| YG8L | 89 | 2000 | 14.6 |
| YG11 | 88.5 | 2600 | 14.4 | It can be used for high compression steel rod and steel tube drawing, working top hammer, perforation and stamping die under greater stress. |
| YG15 | 87 | 2600 | 14 |
| YL50 | 87 | 2600 | 14.4 |
| YG20 | 85 | 2800 | 13.6 | It can be used to make punching film tools, such as punching watch parts, stamping battery shell, tooth paste mould, small size steel ball, screw, nut, etc. |
| YG20C | 83.5 | 2800 | 13.6 | It can be used for cold forging, cold pressing, cold pressing mould in standard parts, bearing, tool industries, etc., and is also useful in warhead and shell staming die. |
| TL40.5 | 82 | 2800 | 13.3 |
| YB50 | 90.5 | 2600 | 14 | It has high hardness and strength, excellent wear resistance, which can be used in the production of IC wireframe, plastic sealing film, drawing die, nozzle, ultra-thin blade, etc. |
| YB20 | 92 | 2200 | 14.5 | It has high hardness, high strength and superior wear-resisting property, which is suitable for low, medium-speed electronic class progressive die and punch and for copper and aluminum thin sheet stamping. |
Notice: Level of surface grinding can be adjusted according to customer demand. (Default: Rough grinding) If you require accurate surface grinding, please contact us.
